Core Java

Vertical and Horizontal Decorating

A decorator pattern is one of the best ways to add features to an object without changing its interface. I use composable decorators quite often and always question myself as to how to design them right when the list of features must be configurable. I’m not sure I have the right answer, but here is some food for thought.





The Apartment (1960) by Billy Wilder
The Apartment (1960) by Billy Wilder

Let’s say I have a list of numbers:

interface Numbers {
  Iterable<Integer> iterate();
}

Now I want to create a list that will only have odd, unique, positive, and sorted numbers. The first approach is vertical (I just made this name up):

Numbers numbers = new Sorted(
  new Unique(
    new Odds(
      new Positive(
        new ArrayNumbers(
          new Integer[] {
            -1, 78, 4, -34, 98, 4,
          }
        )
      )
    )
  )
);

The second approach is horizontal (again, a name I made up):

Numbers numbers = new Modified(
  new ArrayNumbers(
    new Integer[] {
      -1, 78, 4, -34, 98, 4,
    }
  ),
  new Diff[] {
    new Positive(),
    new Odds(),
    new Unique(),
    new Sorted(),
  }
);

See the difference? The first approach decorates ArrayNumbers “vertically,” adding functionality through the composable decorators Positive, Odds, Unique, and Sorted.

The second approach introduces the new interface Diff, which implements the core functionality of iterating numbers through instances of Positive, Odds, Unique, and Sorted:

interface Diff {
  Iterable<Integer> apply(Iterable<Integer> origin);
}

For the user of numbers, both approaches are the same. The difference is only in the design. Which one is better and when? It seems that vertical decorating is easier to implement and is more suitable for smaller objects that expose just a few methods.

As for my experience, I always tend to start with vertical decorating since it’s easier to implement but eventually migrate to a horizontal one when the number of decorators starts to grow.

Reference: Vertical and Horizontal Decorating from our JCG partner Yegor Bugayenko at the About Programming blog.

Yegor Bugayenko

Yegor Bugayenko is an Oracle certified Java architect, CEO of Zerocracy, author of Elegant Objects book series about object-oriented programing, lead architect and founder of Cactoos, Takes, Rultor and Jcabi, and a big fan of test automation.
Subscribe
Notify of
guest

This site uses Akismet to reduce spam. Learn how your comment data is processed.

2 Comments
Oldest
Newest Most Voted
Inline Feedbacks
View all comments
Jacob Zimmerman
8 years ago

You should check out this guy’s idea. It’s my favorite way of composing decorators.
http://blog.codefx.org/design/patterns/decorator-pattern-java-8/

Jacob Zimmerman
8 years ago

Not that yours is bad; it just kind of hides how to decorate (unless you know about the pattern) and requires an additional 2 apis (Modified and Diff).
